Cooler Master Elite 690 Wood ARGB Cabinet (Black)
Cooler Master Elite 690 Wood ARGB ATX Mid Tower in Black
Computer Server Solutions presents the Cooler Master Elite 690 Wood ARGB (Black), an ATX mid tower that blends real-wood accents with high-performance airflow. Dual tempered glass, a vertical cooling path, and three pre-installed ARGB PWM fans deliver a showcase-ready build with modern connectivity, ideal for gaming and creator rigs.
Features
-
Natural wood-accent front with lower mesh intake for airflow
-
270° panoramic view with dual tempered glass panels
-
Vertical cooling architecture; supports up to 9–10 fans
-
Liquid cooling ready: top 360mm and side 240mm support
-
Pre-installed 3x ARGB PWM fans (2x reverse side, 1x rear)
-
USB-C 20Gbps plus dual USB 3.0 on front I/O
-
GPU clearance up to 425mm; CPU cooler up to 170mm
-
Independent PSU chamber for cleaner thermals and cable routing
-
ATX, Micro-ATX, ITX motherboard compatibility
-
Dust filters at top and bottom; 2-year warranty
Specification
| Brand | Cooler Master |
| Model Number / SKU | E690-KHNN-S00 |
| Product Name | Cooler Master Elite 690 Wood ARGB (Black) |
| Color | Black |
| Materials | Front: Tempered Glass + Wood; Left: Tempered Glass; Right: Steel |
| Dimensions (Incl. protrusions) | 434 x 218 x 454mm |
| Dimensions (Excl. protrusions) | 430 x 218 x 435mm |
| Volume | 42.93L |
| Weight | [Provide final weight] |
| Motherboard Support | ATX / Micro-ATX / Mini-ITX |
| Expansion Slots | 7 |
| Drive Bays | 3.5" HDD: 1 (Max 2); 2.5" SSD: 1 (Max 2) |
| Optical Drive | Not supported |
| Pre-installed Fans | Side: 2 x 120mm ARGB PWM (reverse); Rear: 1 x 120mm ARGB PWM |
| Fan Support (Top) | 3 x 120mm or 2 x 140mm |
| Fan Support (Rear) | 1 x 120mm |
| Fan Support (Side) | 2 x 120mm |
| Fan Support (Bottom) | 3 x 120mm |
| Radiator Support (Top) | Up to 360mm (max radiator+fan height 45mm), 240mm, 120mm |
| Radiator Support (Bottom) | 360mm / 240mm / 120mm |
| Radiator Support (Side) | 240mm / 120mm |
| GPU Clearance | Up to 425mm |
| CPU Cooler Clearance | Up to 170mm |
| PSU Support | ATX PSU, up to 250mm length |
| Dust Filters | Top, Bottom |
| Front I/O | 1 x USB Type?C (20Gbps), 2 x USB 3.0, 1 x 3.5mm audio combo |
| Lighting | Addressable RGB (ARGB) with motherboard sync |
| Warranty | 2 Years |
| In the Box | Case, pre?installed fans, accessory pack, documentation |
Notes: Prices, features and specifications are subject to change without notice. Images are for representation purposes only.
Build a stunning, high-airflow showcase PC today. Contact Computer Server Solutions for pricing, availability, and fast delivery.
