Intel® Core™ i7-12700 – Hybrid Power for High-Performance Desktops BX8071512700

Unlock elite computing performance with the Intel® Core™ i7-12700, a 12th Generation desktop processor engineered on the advanced Intel 7 process. Featuring a hybrid architecture with 12 cores (8 Performance-cores + 4 Efficient-cores) and 20 threads, this CPU delivers the ideal balance of speed, multitasking, and energy efficiency for power users, creators, and professionals.

Powerful Clock Speeds and Advanced Memory Support

Achieve a max turbo frequency of up to 4.90 GHz, backed by 25MB Intel® Smart Cache and 12MB L2 Cache for responsive computing. It supports both DDR5 (up to 4800 MT/s) and DDR4 (up to 3200 MT/s) memory, with a maximum capacity of 128GB, enabling flexibility for any modern system build.

Integrated Graphics and Connectivity

Equipped with Intel® UHD Graphics 770, the i7-12700 supports resolutions up to 8K via DisplayPort and 4K via HDMI, ideal for content creators and entertainment setups. PCIe 5.0 and 4.0 support ensures blazing-fast connections with next-gen GPUs and SSDs.

Security, Reliability, and Virtualization

This processor features a full suite of Intel security technologies and vPro® support, making it a top choice for enterprise and business users.

Specifications:

Essentials
Product Collection	12th Generation Intel® Core™ i7 Processors
Code Name	Products formerly Alder Lake
Vertical Segment	Desktop
Processor Number	i7-12700
Lithography	Intel 7
Use Conditions	PC/Client/Tablet
CPU Specifications
Total Cores	12
# of Performance-cores	8
# of Efficient-cores	4
Total Threads	20
Max Turbo Frequency	4.90 GHz
Intel® Turbo Boost Max Technology 3.0 Frequency	4.90 GHz
Performance-core Max Turbo Frequency	4.80 GHz
Efficient-core Max Turbo Frequency	3.60 GHz
Performance-core Base Frequency	2.10 GHz
Efficient-core Base Frequency	1.60 GHz
Cache	25 MB Intel® Smart Cache
Total L2 Cache	12 MB
Processor Base Power	65 W
Maximum Turbo Power	180 W
Supplemental Information
Embedded Options Available	Yes
Memory Specifications
Max Memory Size (dependent on memory type)	128 GB
Memory Types	Up to DDR5 4800 MT/s Up to DDR4 3200 MT/s
Max # of Memory Channels	2
Max Memory Bandwidth	76.8 GB/s
ECC Memory Supported ‡	Yes
Processor Graphics
Processor Graphics	Intel® UHD Graphics 770
Graphics Base Frequency	300 MHz
Graphics Max Dynamic Frequency	1.50 GHz
Graphics Output	eDP 1.4b, DP 1.4a, HDMI 2.1
Execution Units	32
Max Resolution (HDMI)	4096 x 2160 @ 60Hz
Max Resolution (DP)	7680 x 4320 @ 60Hz
Max Resolution (eDP - Integrated Flat Panel)	5120 x 3200 @ 120Hz
DirectX* Support	12
OpenGL* Support	4.5
Multi-Format Codec Engines	2
Intel® Quick Sync Video	Yes
Intel® Clear Video HD Technology	Yes
# of Displays Supported	4
Device ID	0x4680
OpenCL* Support	2.1
Expansion Options
Direct Media Interface (DMI) Revision	4.0
Max # of DMI Lanes	8
Scalability	1S Only
PCI Express Revision	5.0 and 4.0
PCI Express Configurations	Up to 1x16+4, 2x8+4
Max # of PCI Express Lanes	20
Package Specifications
Sockets Supported	FCLGA1700
Max CPU Configuration	1
Thermal Solution Specification	PCG 2020C
TJUNCTION	100°C
Package Size	45.0 mm x 37.5 mm
Advanced Technologies
Intel® Gaussian & Neural Accelerator	3.0
Intel® Thread Director	Yes
Intel® Deep Learning Boost (Intel® DL Boost)	Yes
Intel® Optane™ Memory Supported	Yes
Intel® Speed Shift Technology	Yes
Intel® Turbo Boost Max Technology 3.0	Yes
Intel® Turbo Boost Technology	2.0
Intel® Hyper-Threading Technology	Yes
Intel® Virtualization Technology (VT-x)	Yes
Intel® Virtualization Technology for Directed I/O (VT-d)	Yes
Intel® VT-x with Extended Page Tables (EPT)	Yes
Intel® 64	Yes
Instruction Set	64-bit
Instruction Set Extensions	Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2
Idle States	Yes
Enhanced Intel SpeedStep® Technology	Yes
Thermal Monitoring Technologies	Yes
Intel® Volume Management Device (VMD)	Yes
Security & Reliability
Intel vPro® Eligibility ‡	Intel vPro® Enterprise, Intel vPro® Essentials
Intel® Threat Detection Technology (TDT)	Yes
Intel® Active Management Technology (AMT) ‡	Yes
Intel® Standard Manageability (ISM) ‡	Yes
Intel® One-Click Recovery ‡	Yes
Intel® Hardware Shield Eligibility ‡	Yes
Intel® Control-Flow Enforcement Technology	Yes
Intel® Total Memory Encryption - Multi Key	Yes
Intel® Total Memory Encryption	Yes
Intel® AES New Instructions	Yes
Secure Key	Yes
Intel® OS Guard	Yes
Intel® Trusted Execution Technology ‡	Yes
Execute Disable Bit ‡	Yes
Intel® Boot Guard	Yes
Mode-based Execute Control (MBEC)	Yes
Intel® Stable IT Platform Program (SIPP)	Yes
Intel® Virtualization Technology with Redirect Protection (VT-rp) ‡	Yes
Intel® Virtualization Technology (VT-x) ‡	Yes
Intel® Virtualization Technology for Directed I/O (VT-d) ‡	Yes
Intel® VT-x with Extended Page Tables (EPT) ‡	Yes
Warranty	3 Years
