Cooler Master Elite 490 ARGB Black mATX with 270° glass
The Cooler Master Elite 490 ARGB (Black) is a compact mATX mini tower for performance, airflow, and clean aesthetics. With dual tempered glass front and side panels it supports up to 360mm radiators. It comes pre-installed with three ARGB PWM fans (two reverse-blade side intakes and one rear exhaust) with daisy-chain support for neat cable management and full motherboard lighting sync, I/O includes dual USB 3.0 and a 20Gbps USB 3.2 Gen 2x2 Type-C for high-speed connectivity.
Features
-
270° tempered glass front and side panels for wide hardware visibility
-
Compact mATX form factor with support for full-size cooling and GPUs
-
Vertical cooling layout with support for up to 9 fans
-
Pre-installed 3x ARGB PWM fans with daisy-chain connectors and sync
-
Up to 360mm radiator support (top and bottom), plus side 240mm
-
Top and bottom mesh ventilation for unobstructed airflow
-
High-speed I/O: USB 3.2 Gen 2x2 Type-C (20Gbps) + dual USB 3.0
-
GPU clearance up to 425mm (ready for high-end, next-gen GPUs)
-
CPU cooler clearance up to 170mm; PSU support up to 250mm
-
2-year warranty coverage
| Specification | Detail |
| Brand | Cooler Master |
| Model Number | E490-KHNN-S00 |
| Color | Black |
| Weight | — |
| Dimensions (LxWxH) – Incl. protrusions | 434 x 218 x 414mm |
| Dimensions (LxWxH) – Excl. protrusions | 430 x 218 x 395mm |
| Volume | 39.16L |
| Motherboard Support | Micro-ATX / ITX |
| Expansion Slots | 5 |
| Drive Bays | 3.5" HDD: 1 (max 2); 2.5" SSD: 1 |
| Front Panel | Tempered Glass |
| Left Side Panel | Tempered Glass |
| Right Side Panel | Steel |
| I/O Panel | 1x USB Type-C 20Gbps, 2x USB 3.0, 1x 3.5mm combo |
| Fan Support (Top) | 2x 140mm or 3x 120mm |
| Fan Support (Rear) | 1x 120mm |
| Fan Support (Side) | 2x 120mm |
| Fan Support (Bottom) | 3x 120mm |
| Pre-installed Fans | 2x 120mm ARGB PWM reverse (side), 1x 120mm ARGB PWM (rear) |
| Radiator Support (Top) | 360/240/120mm (max height 45mm) |
| Radiator Support (Bottom) | 360/240/120mm |
| Radiator Support (Side) | 240/120mm |
| CPU Cooler Clearance | 170mm |
| GPU Clearance | 425mm |
| PSU Length Support | 250mm, ATX PSU |
| Warranty | 2 Years |
| Note | Prices, features and specifications are subject to change without notice. Images are for representation purposes only. |
Build a powerful, compact rig with stunning ARGB and full-scale cooling. Contact Computer Server Solutions for best pricing and fast delivery.
